Hydraulic Shears rau Excavator
2. 360 degrees tig.
3. Kev hloov pauv lub puab tsaig lossis cov hniav, kev saib xyuas yooj yim.
4. Nws tuaj yeem ua tau ntau yam ntaub ntawv, suav nrog hlau, pob zeb, thiab lwm yam ntawm cov khoom siv.
|
Qauv |
Yg-290 ob lub tog raj kheej hydraulic shear |
YG-280 excavator shear |
|
Haum excavator |
20-30Tuj |
20-28Tuj |
|
Nqa hnyav |
2800kg ib |
2100 kg ib |
|
Tsav tsheb siab |
320 kgf / cm² |
320-350kgf/cm² |
|
Tsav tsheb khiav |
230-280lpm |
|
|
Qhib |
7 40mm |
4 85mm |
|
Shearing qhov tob |
550 hli |
5 25mm |
|
Nruab nrab txiav quab yuam |
156T |
780T |
|
Ntsis txiav quab yuam |
100T |
200T |
|
Txiav loj rau channel |
400 * 400 * 15mm |
|
|
Txiav loj rau H beams |
280 * 10 hli |
360 hli |
|
Txiav loj rau lub kaum sab xis hlau |
200 * 200 * 20mm |
200 * 15mm |
|
Txiav loj rau steel phaj |
20 hli |
16 hli |
|
Lub sijhawm voj voog |
qhib 2.5s, kaw 4.3s |
8s |
Hydraulic txiab rau excavators yog tshwj xeeb attachments tsim los rau mounted ntawm caj npab los yog boom ntawm hydraulic excavators. Lawv yog cov cuab yeej tseem ceeb hauv ntau qhov kev lag luam uas xav tau kev ua haujlwm zoo thiab raug txiav thiab rhuav tshem.
Muaj pes tsawg hom excavator hydraulic shear muaj?
Ntau tus neeg muas zaub tau hu rau peb kom nug txog hydraulic txiab, tab sis lawv tsis tuaj yeem piav qhia qhov twg hydraulic shear lawv xav tau. Ntawm no peb yuav tham nyob rau hauv kom meej txog yuav ua li cas paub qhov txawv hydraulic shear.
Excavator hydraulic shear muab faib ua ob pawg: txhua yam hom thiab hydraulic hom.
Lub tshuab hom shear siv lub excavator lub thoob lub tog raj kheej los siv lub zog rau cov hlua txuas txuas caj npab, uas tom qab ntawd ua rau lub siab ntawm lub cev shear. Lub hauv qab shear lub cev yog tsau rau lub thoob pas nrig yam tsis tas yuav tsum tau ntxiv cov khoom. Los ntawm kev siv lub tog raj kheej roj thiab hydraulic system, nws tuaj yeem ua haujlwm shearing. Nws muaj cov qauv compact thiab yooj yim rau nruab. Txawm li cas los xij, nws tsis muab lub zog txiav ntau npaum li hydraulic txiab. Ntawm qhov zoo, nws yog tus nqi-zoo thiab yooj yim rau nruab.
Hydraulic excavator hydraulic shear yog muab faib ua taag thiab rotable hom. Lub hydraulic shear ruaj ruaj muaj nws tus kheej hydraulic lub tog raj kheej, uas siv lub thrust ntawm lub tog raj kheej los ua shearing. Qhov zoo dua yog tias lub zog shearing loj, tab sis qhov tsis zoo yog tias nws tsis tuaj yeem tig thiab nws tsis yooj yim nrhiav txoj haujlwm raug thaum dismantling lossis shearing steel qauv.
Rotary hydraulic shear muab faib ua ob hom: ib lub tog raj kheej thiab ob lub tog raj kheej. Lub tog raj kheej tsuas yog siv rau kev txhim kho caj npab rau kev rhuav tshem cov khoom lag luam hauv tsheb, thiab lwm yam. Nyob rau hauv cov ntaub ntawv no, tsis tas yuav muaj ntxiv ib caj npab ntev. Hais txog hais lus, hydraulic shearing quab yuam ntawm ib lub tog raj kheej yog ntau dua li ntawm ob lub tog raj kheej vim nws lub tog raj kheej yog tuab thiab muaj zog dua.
Excavator hydraulic shear kuj tseem siv rau demolition, crushing qhob, txiav ntoo ceg, thiab lwm yam. Hu rau peb hnub no thaum koj xav yuav hydraulic txiab rau excavator.
Cim npe nrov: Tuam Tshoj hydraulic txiab rau excavator, Tuam Tshoj hydraulic shear rau excavator manufacturers
